Nassau
~200 km² gold concession beside Newmont's Merian mine — high-grade quartz veins, alluvial workings ringing a central plateau, and three priority targets ahead of the drill.
A plateau of
untested upside.
Nassau sits on the same Guiana greenstone belt as Sela Creek, about 20 km south of Newmont's producing Merian pit and along regional strike of Zijin's Rosebel mine. Alluvial gold mining rings a central plateau — the classic Guiana signature of a bedrock source feeding the drainages.
Artisanal workings are moving up-slope from placer into weathered bedrock, with ample high-grade quartz vein sets exposed at surface. Three high-priority targets were established by previous operators — the same orogenic system and the same district-scale question as Sela Creek, still ahead of the drill bit.
structurally hosted
greenstone
priority, drill-ready
exploration
Central plateau
Alluvial gold mining rings the plateau — evidence of a bedrock source feeding the drainages all around it.
Miners into bedrock
Artisanal workings are moving up-slope from placer into weathered bedrock and saprolite.
Vein sets exposed
Widespread high-grade quartz veins at surface with excellent grades — ready for systematic drilling.
High grades at surface.
A 3 km long NW-trending geophysical anomaly is interpreted as the bedrock source feeding the placer deposits that ring the plateau — with high-grade quartz veins already assaying to 27.96 g/t Au at surface.
| Sample type & method | n >0.5 g/t | Width | Peak grade | Program |
|---|---|---|---|---|
| Quartz vein grabSelective grab · surface | 31 / 65 | 1.0 m | 27.96 g/t Au | Prior operator |
| Surface rock chipSelective chip · max value | 13 / 250 | — | 3.44 g/t Au | Prior + Miata |
| Geophysical anomaly3 km NW-trending · max rock | — | — | 4.52 g/t Au | Prior operator |
| Auger / saproliteComposite · weathered bedrock | — | 8.0 m | 1.34 g/t Au | Miata program |
